New Industry Products are a form of content that allows industry partners to share useful news, messages, and technology with All About Circuits readers in a way editorial content is not well suited to. Instruments within WaveForms can be cross-triggered, for example, activating an oscilloscope capture based on a received and decoded digital protocol. Entire routines can be scripted to be run on the equipment without the connection to a host PC. The portability is enabled by its stand-alone Linux Mode, where tests are run and data is stored directly to the device. With the included digital power supply, digital outputs, two-channel arbitrary waveform generator, and two dedicated external triggers, the oscilloscope comes with 12 instruments ready to analyze mixed-signal systems through free software.
About 10-15 seconds will pass as it boots and reconnects.
#Digilent analog discovery pro pro#
The 16 dedicated digital channels make the Analog Discovery Pro a true mixed-signal oscilloscope. At this time, an audible click will be heard and the Analog Discovery Pro will disconnect from WaveForms. DIGILENT Analog Discovery Pro 3000 Benchtop Oscilloscopesĭigilent Analog Discovery Pro 3000 Benchtop Oscilloscopes are portable, high-resolution, mixed-signal, 4-channel or 2-channel oscilloscopes offering 14-bit resolution at up to 0.5 gigasamples per second.
